UHMWPE Lining Sheet is a high-performance wear-resistant liner designed to improve material flow and protect equipment from abrasion, impact, and corrosion. It is widely used in hoppers, chutes, silos, truck beds, and bulk material handling systems to reduce maintenance costs and increase operational efficiency.
Lininging Sheet
UHMWPE Lining Sheet is a high-performance cross-linked and glass fiber reinforced polyethylene liner engineered for extreme wear applications. It improves material flow, reduces buildup and bridging, and protects equipment from abrasion in hoppers, chutes, bins, truck beds, and bulk material handling systems.
Ultra-Low Friction
Features an extremely low coefficient of friction, allowing bulk materials to flow smoothly and reducing material buildup, sticking, and blockages.
Exceptional Wear Resistance
Offers wear resistance up to 200% higher than stainless steel, significantly extending equipment service life in abrasive applications.
Superior Impact & Chemical Resistance
Provides excellent resistance to impact, corrosion, acids, alkalis, and chemicals, ensuring reliable performance in harsh operating environments.
Cost-Effective & Lightweight
Weighs only about half as much as steel and can reduce hopper lining costs to approximately one-third of conventional steel solutions while improving operational efficiency.
| Density | ISO 1183-1:2012 g/cm³ 0.96 |
|---|---|
| Tensile Strength | ISO 527-2:2012 MPa 25 |
| Compression Strength | ISO 604:2002 MPa 40 |
| Elongation at Break | ISO 527-2:2012 % 322 |
| Notched Impact Strength | ISO 179-1:2010 kJ/m² 112 |
| Vicat Softening Point | ISO 306:2004 °C 85 |
